Trip Amplifier 1/209
Hardware Description
3.5.5 Testing DIP-Switches
4 DIP-Switches can be used to activate device functions. It is possible to apply them to
switch from HIGH to LOW alarms or any other conceivable change.
Testing can be accomplished via the handheld commmunicator or a personal computer.
(Use the TERMINAL MODE <Alt-E> in the PC-MENU)
P741 <Enter>
P742 <Enter>
P743 <Enter>
P744 <Enter>
Example
Type: P741 <Enter>
Display: P741 = 0
3.5.6 Testing Relay Outputs
There are electro-mechanical relays or solid state relays depending on orders.
Testing can be accompished via the handheld commmunicator or a personal computer.
(Use the TERMINAL MODE <Alt-E> in the PC-MENU)
(Set jumper MODE to ENABLE)
P751 = 1 <Enter>
P751 = 0 <Enter>
P752 = 1 <Enter>
P752 = 0 <Enter>
P753 = 1 <Enter>
P753 = 0 <Enter>
P754 = 1 <Enter>
P754 = 0 <Enter>
Example
Type: P751 = <Enter>
Display: P751 = 0
shows DIP-Switch 1 (the value is 0 or 1)
shows DIP-Switch 2 (the value is 0 or 1)
shows DIP-Switch 3 (the value is 0 or 1)
shows DIP-Switch 4 (the value is 0 or 1)
Relay 1 energized
Relay 1 deenergized
Relay 2 energized
Relay 2 deenergized
Relay 3 energized
Relay 3 deenergized
Relay 4 energized
Relay 4 deenergized
