Trip Amplifier 1/209
Software Description
Use MODE to exit the SET MODE.
Move to END and activate using EXE.
You are now back with the COMMS-MENU.
Move to TERM to activate the terminal mode pressing EXE.
SHIFT keys give access to second function keys. (Shift-P = 5).
DEL deletes entries.
This key also acts as CTRL.
Pressing EXE again will now connect you to the trip amplifier 1/209.
4.3

Parameter Entries

All device READ/WRITE data is accessible via parameter numbers (e.g. P100).
A personal computer will offer user friendly MENU support.
Read a parameter by entering the parameter number followed by <EXE> on the pr439.
Example
Read constant 1
User: P801 <EXE>
Display: P801 = 123.456
In case an unknown parameter is addressed the system will return 0.
Example
Unknown parameter
User: P428 <EXE>
Display: P428b = 0
Change a parameters by entering the parameter number followed by an = sign and the
new value. Values are automatically stored in EEPROM. Illogical values will not be
accepted.
Example
Set constant 1
User: P801= 100 <EXE>
Display: P801= 100
72
