Device Layout - Pepperl+Fuchs 1/209 Handbuch

Trip Amplifier 1/209
Technical Data
2.12

Device Layout

1
K1
K2
K3
PS
1 Display
2 KEY, MODE, CLASS jumper
3 Line fuse
4 Space for label
5 Processor
K1 Push button
K2 Push button
K3 Push button
PS Programming socket
S1 Function Selector Switch
D Digital Input/Output
Jumper 5 V, 10 V, 20 mA
60
2
S1
4
5
3
D
10 V 5 V 20 mA
B
