Pepperl+Fuchs ICE11-8IOL-G60L-V1D Handbuch Seite 68

ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
Attribut
10
11
13
Tabelle 6.47
Ethernet Link Object 0xF6
Unterstützte Dienste:
• Get Attribute Single 0x0E
• Set Attribute Single 0x10
• Get and Clear 0x4C
Class-Attribut, Instanz 0
Attribut
1
2
3
Tabelle 6.48
1. In this case number of ethernet ports
Instance-Attribut, Instanz 1 ... 2
Attribut
1
2
3
4
68
Name Zugang
Select Acd Get, Set
Last Conflict Detected Get, Set
Encapsulation Inacti- Get, Set
vity Timeout
Name Zugang
Revision Get
Max. Instance Get
Number of Instances Get
Name Zugang
Interface Speed Get
Interface Flags Get
Physical Address Get
Interface Counters Get
Datentyp Beschreibung
BOOL Enables "1" or disables "0" the use
of ACD, default value "1"
STRUCT Structure containing information
related to the last conflict detected
UINT Number of seconds of inactivity
before TCP connection is closed:
0 = disable
1 ... 3600 = timeout in seconds
120 = default value
Datentyp Beschreibung
UINT Revision of this object
UINT Maximum instance number of an
object currently created in this
class level of the device
UINT Number of object instances cur-
rently created at this class level of
1
the device
Datentyp Beschreibung
UDINT Current Interface speed in Mbps
DWORD Interface Flags:
b0: Link Status
b1: Half "0" or Full "1" Duplex
b2 ... 4: Negotiation Status:
0 = Auto-negotiation in progress
1 = Auto-negotiation and speed
detection failed (using default
10Mbps and half duplex)
2 = Auto negotiation failed but
detected speed (using default half
duplex)
3 = Successfully negotiated speed
and duplex
4 = Auto-negotiation not attemp-
ted (forced speed and duplex)
b5: Manual Setting Requires
Reset
b6: Local Hardware Fault
b7 ... 31: Reserved "0"
ARRAY MAC address
STRUCT Interface Counters
