ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
Attribut
7
8 ... 9
10
Tabelle 6.56
IO-Link Diagnosis Settings Object 0xA2
Unterstützte Dienste:
• Get Attribute Single 0x0E
• Set Attribute Single 0x10
Class-Attribut, Instanz 0
Attribut
1
2
Tabelle 6.57
Instance-Attribut, Instanz 1 ... 16
Attribut
1
2
3
4
5 ... 12
Tabelle 6.58
Name Zugang
DI Filter Get, Set
Reserved
Channel Mode Get, Set
Name Zugang
Revision Get
Max. Instance Get
Name Zugang
IO-Link Master Dia- Get, Set
gnosis
IO-Link Device Error Get, Set
IO-Link Device War- Get, Set
ning
IO-Link Device Notifi- Get, Set
cation
IO-Link Device Dia- Get, Set
gnosis Port 1 ... 8
Datentyp Beschreibung
SINT 0: Disabled
1: 1 ms
2: 2 ms
3: 3 ms
4: 6 ms
5: 10 ms
6: 15 ms
SINT 0: Inactive
1: Digital Output
2: Digital Input
3: IO-Link
4: Auxiliary Power
Datentyp Beschreibung
UINT Revision of this object
UINT Maximum instance number of an
object currently created in this
class level of the device
Datentyp Beschreibung
BOOL 0: Disable
1: Enable
BOOL 0: Disable
1: Enable
BOOL 0: Disable
1: Enable
BOOL 0: Disable
1: Enable
BOOL 0: Disable
1: Enable
