ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
QoS Object 0x48
Unterstützte Dienste:
• Get Attribute Single 0x0E
• Set Attribute Single 0x10
Class-Attribut, Instanz 0
Attribut
1
2
6
7
Tabelle 6.44
Instance-Attribut, Instanz 1
Attribut
1
2
3
4
5
6
7
8
Tabelle 6.45
66
Name Zugang
Revision Get
Max. Instance Get
Maximum ID Number Get
Class Attributes
Maximum ID Number Get
Instance Attributes
Name Zugang
802.1Q Tag Get, Set
Enable
DSCP PTP Event Get, Set
DSCP PTP Get, Set
General
DSCP Urgent Get, Set
DSCP Scheduled Get, Set
DSCP High Get, Set
DSCP Low Get, Set
DSCP Explicit Get, Set
Datentyp Beschreibung
UINT Revision of this object
UINT Maximum instance number of an
object currently created in this
class level of the device
UINT The attribute ID number of the last
class attribute of the class defini-
tion implemented in the device
UINT The attribute ID number of the last
instance attribute of the class defi-
nition implemented in the device.
Datentyp Beschreibung
USINT Enables "1" or disables "0" sen-
ding 802.1Q frames on CIP and
IEEE 1588 messages, default
value "0"
USINT DSCP value for PTP Event fra-
mes, default value "59"
USINT DSCP value for PTP General fra-
mes, default value "47"
USINT CIP transport class 0/1 messages
with Urgent priority, default value
"55"
USINT CIP transport class 0/1 messages
with Scheduled priority, default
value "47"
USINT CIP transport class 0/1 messages
with High priority, default value
"43"
USINT CIP transport class 0/1 messages
with Low priority, default value "31"
USINT CIP UCMM, CIP transport class
2/3, All other EtherNet/IP
encapsulation messages, default
value "27"
