ICE11-8IOL-G60L-V1D
Inbetriebnahme bei PROFINET
I&M0-Daten
IM_RevisionCounter
IM_Profile_ID
IM_Profile_Specific_Type
IM_Version
IM_Supported
Tabelle 7.15
"Read"-Beispiel I&M5 an Port X1 mit angeschlossenem IOL-Device
Abbildung 7.50
I&M 5
I&M5-Daten
IM_Annotation
IM_OrderID
IM_VendorID
IM_Serial_Number
IM_Hardware_Revision
116
Oktette
2
2
2
2
2
I&M 0 (Slot 1: IO System 1.2 - 1.9, Index 0xAFF0)
Oktette
64
64
2
16
2
Daten-
typ Mapping-Regel
Unsi- Set to "0" (0x0000)
gned16
Unsi- IO-Link (API = 0x4E01)
gned16
Unsi- Set to "0" (0x0000)
gned16
2 x Unsi- Octet 1 (MSB): set to 0x01
gned8 Octet 2 (LSB): set to 0x00
Unsi- Profile specific I&M: 0x0000 (Bit 0 for
gned16 I&M0 is always 0)
(Bit Array)
Daten-
typ Mapping-Regel
String "IO-Link Devices"
(UTF8)
Visible "Product Name" or "DeviceID"
String
Unsi- "VendorID"
gned16
Visible Insert SerialNumber of device (IO-
String Link Index 21). If it is not available,
set to "Not accessible".
Unsi- Set to 0x0000 (default value)
gned8
