ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
Konfigurations-
Parameter
Output Data Swap-
ping Offset
Input Data Swapping
Mode
Input Data Swapping
Offset
IOL Failsafe
Port Mode
Validation and Bac-
kup
Vendor ID
Device ID
Cycle Time
Tabelle 6.17
1. transferred via IO-Link Failsafe Parameter Object
Byte-Offset
Konfig.-
Assembly Datentyp Gültige Werte
228, 250, 272, SINT
294,
316, 338, 360,
382
229, 251, 273, SINT
295,
317, 339, 361,
383
230, 252, 274, SINT
296,
318, 340, 362,
384
231, 253, 275, SINT
297,
319, 341, 363,
385
232, 254, 276, SINT
298,
320, 342, 364,
386
233, 255, 277, SINT
299,
321, 343, 365,
387
234, 256, 278, DINT
300,
322, 344, 366,
388
238, 260, 282, DINT
304,
326, 348, 370,
392
242, 264, 286, SINT
308,
330, 352, 374,
396
0 ... 30 Byte, "0"
0: Raw IO-Link Data
1 ... 16: 1 ... 16 WORD
17 ... 24: 1 ... 8 DWORD
0 ... 30 Byte, "0"
0: Set Low
1: Set High
2: Hold Last
1
3: Replacement Value
4: IO-Link Master Com-
mand
0: Deactivated
1: Manual, with validation
and backup config
2: Autostart, no valida-
tion and backup config
0: No device check and
clear, no data storage
1: Type compatible, V1.0
device, no data storage
2: Type compatible, V1.1
device, no data storage
3: Type compatible, V1.1
device with Backup +
Restore, download +
upload
4: Type compatible, V1.1
device with Restore,
download master to
device
0 ... 65535, "0"
0 ... 16777215, "0"
0: As fast as possible
1: 1.6 ms
2: 3.2 ms
3: 4.8 ms
4: 8.0 ms
5: 20.8 ms
6: 40.0 ms
7: 80.0 ms
8: 120.0 ms
CIP-Objekt-
klasse 0xA3,
Instanz 1 ... 8
Attribute 5
Attribute 6
Attribute 7
Attribute 8
Attribute 9
Attribute 10
Attribute 11
Attribute 12
Attribute 13
35
