ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
Attribut
5
6
7
8
9
19
Tabelle 6.37
Name Zugang
Status Get
Serial Number Get
Product Name Get
State Get
Configuration Consi- Get
stency Value
Protection Mode Get
Datentyp Beschreibung
WORD Summary status of device:
b0: Owned
b1: Reserved "0"
b2: Configured
b3: Reserved "0"
b4 ... 7: Extended Device Status
0 = Self-Testing or Unknown
1 = Firmware Update in Progress
2 = At least one faulted I/O
connection
3 = No I/O connections establis-
hed
4 = Non-Volatile Configuration bad
5 = Major Fault
6 = At least one I/O connection in
RUN mode
7 = At least one I/O connection
established, all in IDLE mode
8 = Unused, valid only for
instances grater than "1"
9 = Reserved
10 ... 15 = Vendor specific
b8: Minor Recoverable Fault
b9: Minor Unrecoverable Fault
b10: Major Recoverable Fault
b11: Major Unrecoverable Fault
b12 ... 15: Reserved, "0"
UDINT Serial number of device
STRING Human readable identification
USINT Present state of the device:
0 = Nonexistent
1 = Device Self Testing
2 = Standby
3 = Operational
4 = Major Recoverable Fault
5 = Major Unrecoverable Fault
6 ... 254 = Reserved
255 = Default Value
UINT Can be a CRC, incrementing
count or any other mechanism,
vendor specific behavior) to reflect
a non-volatile configuration
change
WORD Current protection mode of the
device:
b0: Implicit Protection enabled
b1 ... 2: Reserved
b3: Explicit Protection enabled
b4 ... 15: Reserved
