ICE11-8IOL-G60L-V1D
Inbetriebnahme bei EtherNet/IP
Extended-Status
IO-Link Extended
Status
Extended Diagno-
stics
Vendor ID
Device ID
Tabelle 6.30
OLE
ILE
SPE
BUI
ICT
0
Events
IO-Link Events
Event Qualifier 1
Event Code 1
Event Qualifier 2
Event Code 2
Event Qualifier 3
Event Code 3
Tabelle 6.31
Instance
Type
Mode
44
Bit Bit 7 Bit 6
Byte 0, 0 0
LSB
Byte 1, 0
MSB
Byte 2 Vendor ID, LSB
Byte 3 Vendor ID, MSB
Byte 4 Device ID, LSB
Byte 5 Device ID
Byte 6 Device ID, MSB
Byte 7 0
Längen-Fehler der Output- Prozessdaten, device mismatch
Längen-Fehler der Input-Prozessdaten, device mismatch
Startup Parameterization Error = direkter Parameter-Fehler
Backup Inconsistency = Parameter- Speicherfehler
Ungültige Zykluszeit
Reserviert
Bit Bit 7 Bit 6
Byte 0, Mode
LSB
Byte 1, 0 0
MSB
Byte 2 Event Code
Byte 3
Byte 4 Mode
Byte 5 0 0
Byte 6 Event Code
Byte 7
Byte 8 Mode
Byte 9 0 0
Byte 10 Event Code
Byte 11
Unknown; "0", Reserved; Physical Layer PL; "1", Data Link Layer DL;
"2", Application Layer AL; "3", Application; "4"
Benachrichtigung; "1", Warnung; "2", Fehler; "3"
Event single shot; "1", Event verschwunden; "2", Event aufgetaucht; "3"
Bit 5 Bit 4 Bit 3 Bit 2
0 ICT BUI SPE
Bit 5 Bit 4 Bit 3 Bit 2
Type 0 0
0 0 0 0
Type 0 0
0 0 0 0
Type 0 0
0 0 0 0
Bit 1 Bit 0
ILE OLE
Bit 1 Bit 0
Instance
0 0
Instance
0 0
Instance
0 0
