Inbetriebnahme bei EtherNet/IP
Modifizierte Prozessdaten
Byte-
Offset
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
Tabelle 6.34
48
Ausgangsdaten
Digital output channel control, 2 bytes
Reserved, 2 bytes
IO-Link port 1 data, control, 2 bytes
IO-Link port2 data, control, 32 bytes
IO-Link port3 data, control, 16 bytes
IO-Link port4 data, control, 8 bytes
Eingangsdaten
Digital input channel control, 2 bytes
General diagnostics, 2 bytes
Sensor diagnostics, 2 bytes
Actuator diagnostics, 2 bytes
IO-Link diagnostics, 6 bytes
IO-Link port 1 data, status, 2 bytes
IO-Link port 1 PQI, 2 bytes
IO-Link port 2 PQI, 2 bytes
IO-Link port 2 extended status, 8 bytes
IO-Link port 3 data, status, 4 bytes
IO-Link port 3 PQI, 2 bytes
IO-Link port 3 extended status, 8 byte
IO-Link port 3 events, 12 bytes
IO-Link port 4 data, status, 2 bytes
IO-Link port 4 PQI, 2 bytes
IO-Link port 5 PQI, 2 bytes
IO-Link port 6 PQI, 2 bytes
IO-Link port 7 PQI, 2 bytes
IO-Link port 8 PQI, 2 bytes
