1. Lay the closed part of the sling
over the support top rails.
–
Connect the buckles.
–
Adjust the straps as
necessary for the
amount of slack you
want in the sling.
Hip and Thigh Supports
NOTE:
The thigh supports are side-specific.
1. Determine which size hip support to
use, and then do as follows to install
each support on the support top:
a. Put the support in position on the
top. Make sure the clamp side of
the support is toward the outside
of the top.
Thigh support—make sure the support
will be in a position to support the patient's upper thigh area.
Hip support—make sure the support will be in a position that is in between
the patient's iliac crest and the top of the pelvic bone.
2. Close the blue clamp on to the locking
posts.
3. Slide the blue clamp to the locked
position. When locked, only the green
area will show on the pin.
NOTE:
Look under the rail to make sure the
clamp is correctly engaged on the
locking posts.
