SYMBOL IDENTIFICATION
Symbol
10 Allen® Advance Table User Manual (80028190)
Tilt Right control - turns a support top up to 25°
clockwise.
Identifies the controls in the area as column
height controls. This is not a control.
Up control - raises both columns at the same
time.
Down control - lowers both columns at the same
time.
Trendelenburg control - lowers the head-end
column as it raises the foot-end column.
Reverse Trendelenburg control - raises the head-
end column as it lowers the foot-end column.
Identifies the controls in the area as brake
controls. This is not a control.
Lock control - locks the brakes.
Description
