CONTROLS AND INDICATORS

You will find the different controls and indicators for the Allen Advance
Table on the cross tube, on both columns, and on the pendant.
You will find these controls and indicators on the head-end base:
Model number label
Serial number label
Plug outlet
On/Off switch
Equipotential ground point
Manual brake release (red handle
on both columns)
Power indicator—when on, the
Allen Advance Table is plugged
in.
Battery charge level
Allen® Advance Table User Manual (80028190)
CONTROLS AND INDICATORS
Page Item
22 O Battery charge
level
22 P Power indicator
22 Q Emergency brake
release
19 R Pendant connector 46
S Cervical traction
release
Feature
20
19
21
39
17
