DISCARD THE UNIT

When correctly maintained, the battery has an expected life of 3
years.
DISCARD THE UNIT
When the Allen Advance Table has reached the end of its useful life,
discard it in accordance with local standards. Recycle as much as possible.

PARTS REPLACEMENT

WARNING:
Only facility-authorized maintenance persons should do these parts
replacement procedures. Otherwise, patient fall, injury, or equipment
damage could occur.
WARNING:
Always wear the applicable personal protective equipment when you
service the unit. Failure to do so could cause injury.
WARNING:
Before you remove and replace electrical components (power cord, pendant,
fuses), make sure to remove power from the Allen Advance Table.
Otherwise, patient fall, injury, or equipment damage could occur.
The parts shown below can be replaced by facility -authorized maintenance
persons. If additional parts need to be replaced, contact Allen Medical
Technical Support.

Pendant

Pendant nut
H-bracket
Cross pin
Power cord, EU
Power cord, UK
Power cord, US
Fuse, 5 mm x 20 mm, 6.3 A, 250 V, slow blow
(A-71100-XX*)
Fuse, 5 mm x 20 mm, 3.15 A, 250 V, slow blow
(A-71101-XX)
* XX is a placeholder for the country code.
P
ENDANT
Removal
46 Allen® Advance Table User Manual (80028190)
Description Quantity Part
Number
1 A-71403
1 C-007239
1 A-71402
1 A-71401
1 A-71407
1 A-71406
1 A-71405
2 C-007318
2 C-007358
