English
In position B, please read the bottom scale; It will be from
200 mm to 880 mm.
4. Adjusting bevel indicator (FIG. 36)
Adjust the red line on the bevel indicator if it is not aligned
with zero when the blade is perpendicular to the table.
◌ With blade perpendicular to table, loosen screw (98).
◌ Set the bevel indicator (8) to align with 0° on bevel
scale (7).
◌ Retighten screw (98).

MAINTENANCE

WARNING
When servicing, use only identical replacement parts.
Use of any other part may create a hazard or cause
product damage.
WARNING
Always wear eye protection during power tool operation
or when blowing dust. If operation is dusty, also wear a
dust mask.
WARNING
Before performing any maintenance, make sure the tool
is unplugged from the power supply and switch is in the
off position.
WARNING
DO NOT at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastics parts. Chemicals can damage, weaken, or
destroy plastic.
WARNING
Make sure the blade guard is reinstalled immediately after
finishing any maintenance which requires it to be removed.
Failure to heed this instruction could result in serious
personal injury.
1. General maintenance
◌ Avoid using solvents when cleaning plastic parts. Most

TROUBLESHOOTING

WARNING
To avoid injury from an accidental start, turn the switch OFF and always remove the plug from the power source before
making any adjustments.
All electrical or mechanical repairs should be done only by qualified service technicians. Contact HiKOKI Authorized
Service Center.
Consult HiKOKI Authorized Service Center if for any reason the motor will not run.
PROBLEM
Saw will not start.
Does not make 45° and 90°
rip cuts.
Material pinches blade when
ripping.
Material binds on riving knife.
PROBLEM CAUSE
◌ Overload tripped.
◌ Saw is not plugged in.
◌ Fuse blown or circuit breaker tripped.
◌ Cord is damaged.
◌ Positive stop not adjusted correctly.
◌ Bevel angle pointer not set accurately.
◌ Rip fence not properly aligned.
◌ Rip fence not aligned with blade.
◌ Warped wood, edge against fence is not
straight.
◌ Riving knife not aligned correctly with
blade.
plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their
use. Use clean cloths to remove dirt, dust, oil,
grease,etc.
◌ Periodically check all clamps, nuts, bolts, and screws
for tightness and condition. Make sure the table insert
is in good condition and level with the working table.
◌ Check the blade guard assembly after performing
maintenance to make sure it is installed correctly and
functioning properly.
◌ Clean plastic part only with a soft damp cloth. DO NOT
use any aerosol or petroleum solvents.
2. Lubrication
All of the bearings in this tool are lubricated with a sufficient
amount of high grade lubricant for the life of the unit under
normal operating conditions. Therefore, no further
lubrication is required.
3. Service and repairs
All quality power tools will eventually require servicing or
replacement of parts because of wear from normal use.
To assure that only authorized replacement parts will be
used and that the double insulation system will be protected,
all service (other than routine maintenance) must be
performed by an HiKOKI Authorized Service Center
ONLY.
NOTE
Specifications are subject to change without any obligation
on the part of HiKOKI.
4. Storage
After operation of the tool has been completed, check that
the following has been performed:
◌ Switch is in OFF position.
◌ Power plug has been removed from the receptacle.
When the tool is not use, keep it stored in a dry place
out of the reach of children.
CORRECTIVE ACTION
◌ Allow motor to cool and reset by
pushing overload reset switch.
◌ Plug in saw.
◌ Replace fuse or reset circuit breaker.
◌ Have the cord replaced by an
Authorized Service Center.
◌ See section "Bevel adjustment".
◌ See section "Adjusting bevel indicator".
◌ See section "Aligning rip fence to blade".
◌ See section "Aligning rip fence to blade".
◌ Select another piece of wood.
◌ Align riving knife with blade.
