Blade guard
1
Narrow fence
2
Rip fence lock lever
3
Adjusting knob
4
Handle I
5
Adjustable foot
6
Bevel scale
7
Bevel indicator
8
Overload reset switch
9
Foot
10
Stand leg
11
Wheel
12
Power cord
13
Blade wrench
14
Outfeed support
15
Riving knife
16
Rear rail
17
Rip fence
18
Blade guard storage
19
Foot mat
20
Height/bevel adjusting handwheel
21
Height adjusting knob
22
Bevel lock lever
23
Switch assembly
24
Front rail
25
Stand support assembly
26
Scale
27
Mitre gauge
28
Table insert
29
Saw blade
30
Mitre gauge groove
31
Lock pin
32
Dust extraction port
33
Small baffle
34
Anti-kickback pawls storage
35
Push stick storage
36
Fence rails lock lever
37
Push stick
38
Handle II
39
Lock knob
40
Working table
41
Front fence rail
42
Rip fence scale indicator
43
Mitre gauge lock knob
44
Blade wrench storage
45
Power cord storage
46
Mitre gauge storage
47
Anti-kickback pawls
48
49 Rear fence rail
English
Table saw assembly
50
Stand assembly
51
Flat round head screws M8 x 45
52
Lock nut M8
53
Flat round head screws M8 x 10
54
Big flat washer 10
55
Lock nut M10
56
Wheel shaft
57
Wheel assembly
58
Flat round head screws M8 x 100
59
Set screw
60
Riving knife lock knob
61
Inner blade flange
62
Arbour
63
Arbour nut
64
Outer blade flange
65
Ring
66
Knob
67
Slot A
68
Spring pin
69
Pin
70
Hole
71
Knob
72
Pin
73
Pin
74
Slot B
75
Slot C
76
Set screw
77
Stop screw
78
Extension pole
79
Lock knob
80
Position screw
81
Slot
82
Guide rail
83
Switch cover
84
Switch I
85
Switch paddle
86
Hole
87
Support
88
Screw
89
Flat washer
90
Framing square
91
90° stop set screw
92
Triangle square
93
45° stop set screw
94
Screw
95
Screw
96
Red pointer
97
Screw
98
