English
cut operations. The "MIDDLE" position is for non-through
cuts (with blade guard and anti-kickback pawls removed).
Through cutting riving knife installation
◌ Unplug the saw.
◌ Remove the table insert.
◌ Set the saw blade angle to 0°.
◌ Raise the saw blade to the uppermost position by
turning the height adjusting knob (22) clockwise.
◌ Lock the blade by turning bevel lock lever (23)
clockwise.
◌ Unlock riving knife lock knob (61) by turning it
clockwise.
◌ Grasp the riving knife (16) and pull toward right side of
saw to release it from spring-loaded lock pin.
◌ Position the riving knife in the uppermost position with
springloaded lock pin is re-engaged.
◌ Lock the riving knife lock knob (61) by turning it
counter- clockwise.
◌ Reinstall the table insert.
WARNING
Be extremely careful when adjust the riving knife
position.
Do not allow hands to contact blade.
To place riving knife in middle position, refer to the
above procedure.
8. Removing and installing the blade (Fig. 8a-8b)
CAUTION
Check the arbor hole diameter of the blade before
installing the blade. Always use the correct ring for the
arbor hole of the blade you intend to use.
CAUTION
To work properly, the saw blade teeth must point down
toward the front of the saw. Failure to heed this
instruction could cause damage to the saw blade, the
saw or the workpiece.
WARNING
Make sure that the saw blade is installed to rotate in the
proper direction. Do not use grinding wheels, wire
brushes, or abrasive wheels on a table saw. Improper
saw blade installation or use of accessories not
recommended may cause serious injury.
WARNING
Only use a 254 mm diameter blade. To avoid injury from
an accidental start, make sure the switch is in the OFF
position and the plug is not connected to the power
source outlet.
◌ Unplug the saw.
◌ Turn height adjustment knob clockwise to raise blade
to maximum height.
◌ Remove the table insert.
◌ Set the saw blade angle to 0° and raise the saw blade
to the uppermost position.
◌ Remove the blade wrenches from storage area.
Remove the blade:
◌ Using one opened-ended blade wrench (14), place the
flat open end on the flats on the inner blade flange
(62).
◌ Using the other opened-ended blade wrench (14),
place the flat open end on the flats on the arbor nut
(64). Holding both
opened-ended blade wrench on the arbor nut (64)
forward to the front of the machine.
◌ Remove arbor nut (64), outer blade flange (65), saw
wrenches firmly, pull
blade (30) and ring (66).
WARNING
Be extremely careful when loosening arbor nut. Keep
firm grasp on both wrenches. Do not allow hands to slip
and contact blade.
Install the blade:
◌ Place the ring (66) and one new blade on arbor (63).
Make sure saw blade teeth point down at the front side
of saw table. Place outer blade flange (65) and arbor
nut (64) on arbor and use blade wrenches to tighten nut
securely. DO NOT over tighten.
CAUTION:
The ring 30 mm in outer diameter is factory-installed onto
the arbor
WARNING
The large, flat surface of the outer blade flange faces the
saw blade and the saw blade (30) is firmly seated against
the inner blade flange (62).
WARNING
The saw blade (30) should be aligned with the riving knife
(16) and ensuring there is a gap of 3 to 8 mm between
the blade teeth and the riving knife (16).
◌ Lower the saw blade to lowest position and replace
table insert.
WARNING
If the inner blade flange has been removed, reinstall it
before placing the saw blade on arbor. Failure to do so
could cause an accident.
9. Anti-kickback pawls installation (Fig. 9a-9b)
Anti-kickback pawls should only be installed for through
cuts.
WARNING
Make sure the anti-kickback pawls are reinstalled
immediately after finishing any non-through cut operations
which require their removal.
WARNING
Replace dull or damaged anti-kickback pawls. Dull or
damaged anti-kickback pawls may not stop a kickback,
increasing the risk of serious personal injury.
◌ Unplug the saw.
◌ Set the blade angle to 0°.
◌ Raise the saw blade to maximum height by turning
height adjusting knob clockwise.
◌ Lock the blade by turning bevel lock lever clockwise.
◌ Place the riving knife in the highest position.
◌ Pull out and hold knob (67) and push anti-kickback
pawls up, remove it from the anti-kickback pawls
storage (35) located on inside of the left side of saw.
(Fig. 9a)
◌ Pull out and hold knob (67). Align slot in anti-kickback
pawls (48) over the slot A (68) indicated of riving knife
(16). Place the spring pin (69) on the anti-kickback
pawls (48) into the slot (A) (68) indicated on the riving
knife (16).
◌ Press anti-kickback pawls (48) down until it snaps into
place and release knob (67) to insert the pin (70) into
hole (71) indicated on the riving knife (16).
CAUTION
Pull up on anti-kickback pawl assembly to make sure it is
the
secured to riving knife.
WARNING
Gently pull up the anti-kickback pawls to ensure it is
42
