SPECIFICATIONS

Input Voltage
Power Input
n
No Load Speed o
Blade Size
Bevel Range
Working Table Size
Outfeed Support Size
Max. cutting depth at 0°
Max. cutting depth at 45°
Max. rip to left to blade
Max. rip to right to blade
Protection class
Weight
Sound pressure level L
pA
Sound power level L
WA
Uncertainty K , K
pA WA
The sound emission values have been obtained according to the noise test code given in EN 62841-1 and EN 62841-3-1
The noise for the operator may exceed 80 dB(A) and ear protection measures are necessary.

LOOSE PARTS

The following items are included with your table saw: (Fig. 2)
A: Table saw assembly ......................................................
B: Mitre gauge (in stored position) .....................................
C: Blade guard assembly (in stored position) ....................
D: Anti-kickback pawls assembly (in stored position) ........
E: Outfeed support assembly ............................................
F: Rip fence assembly (in stored position) .........................
G: Push stick (in stored position) .......................................
H: Stand support assembly ...............................................
I: Wheel shaft ...................................................................
J: Wheel ............................................................................
K: Stand assembly ............................................................
ASSEMBLY
1. Unpacking your table saw
This product requires assembly.
◌ Carefully lift saw from the carton and place it on a level
work surface.
◌ Inspect the tool carefully to make sure that no
breakage or damage occurred during shipping.
◌ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the tool.
◌ The saw is factory set for accurate cutting. After
assembling it, check for accuracy. If shipping has
influenced the settings, refer to specific procedures
explained in this Operator's Manual.
◌ If any part is missing or damaged, do not attempt to
assemble the table saw, plug in the power cord, or turn
the switch ON until the missing or damaged part is
obtained and is installed correctly.
CAUTION
This tool is heavy. To avoid back injury, lift with your legs,
220-240V~, 50Hz
1500W
4500/min
ø254mm × ø30mm × 2.8mm, 40T
0°~45°
730mm x 559mm
730mm x 50mm
79mm
57mm
440mm
880mm
II/
44kg
94.8 dB(A)
107.8 dB(A)
3 dB(A)
1 L: Handle I assembly ........................................................
1 M: Flat round head screws M8 x 45 ...................................
1 N: Lock nut M8 ..................................................................
1 O: Flat round head screws M8 x 10 ..................................
1 P: Flat round head screws M8 x 100 .................................
1 Q: Big flat washer 10 .........................................................
1 R: Lock nut M10 .................................................................
1 S: Blade wrench ................................................................
1 T: 5mm Hex key ................................................................
2 U: 4mm Hex key ................................................................
1 V: 2.5mm Hex key .............................................................
not your back, and get help when needed.
WARNING
Remove the protective polyfoam from between the saw's
housing and the motor.
WARNING
The use of attachments or accessories not listed in this
manual might be hazardous and could cause serious
personal injury.
WARNING
Do not attempt to modify this tool or create accessories
not recommended for use with this tool. Any such
alteration or modification is misuse, and could result in a
hazardous condition leading to possible serious personal
injury.
WARNING
Do not connect to the power supply until assembly is
complete. Failure to comply could result in accidental
starting and possible serious personal injury.
