RP-R-4042B2, 4064B2
CHAPTER 7 – INSTALLATION
Only skilled technicians, appointed by the manufacturer, or by authorized
dealers, must be allowed to carry out installation. Serious damage to people and
to the lift can be caused if installations are made by unskilled personnel.
Always refer to the exploded views attached during installation.
7.2 TOOL REQUIRED
✟ Rotary Hammer Drill D.19
✟ Masonry Bit
✟ Hammer
✟ Level
✟ Open-End Wrench Set
✟ Medium Crescent Wrench
7.2 CHECKING FOR ROOM SUITABILITY
The lift has been designed to be used in covered and sheltered places.
The place of installation must not be next to washing areas, painting workbenches, solvent or varnish
deposits. The installation near to rooms, where a dangerous situation of explosion can occur, is
strictly forbidden. The relevant standards of the local Health and Safety at Work regulations, for
instance, with respect to minimum distance to wall or other equipment, must be observed.
7.3 LIGHTING
Lighting must be carried out according to the effective regulations of the place of installation. All
areas next to the lift must be well and uniformly lit.
7.4

INSTALLATION SURFACE

The lift must be placed concrete surface sufficiently resistant. The surface must be suitable for
bearing maximum stress values, also in unfavorable working conditions. New concrete must be
adequately cured by at least 21 days minimum. For installations on raised surface, compliance with
the maximum carrying capacity of the surface is recommended.
A level floor is suggested for proper installation. Small differences in floor
slope may be compensated for by proper shimming. Any major slope change
will affect the level lifting performance. If a floor is of questionable slope (more
than 3 degrees), considering to pour the new concrete slab.
7.5 SITE LAYOUT
• Determine which end of the lift will be approach side.
• Determine which side the power-side runway (with the hydraulic cylinder attached) will be
located on. Remember that the power-side runway must be installed on the same side as the
power-side column.
REV. 01
RP-TOOLS Werkstatt-Technik
45 / 94
✟ Hex-Key/Allen Wrench Set
✟ Crow Bar For Shim Installation
✟ Chalk Line
✟ Medium Cross Screwdriver
✟ Medium Flat Screwdriver
✟ Tape measure
