RP-R-4042B2, 4064B2
Jack operation can be summarized into three steps:
Never operate the jacking beam with any person.
Never exceed the rated lifting capacity 3200kg.
Pay attention that the capacity sliding adaptor extension is 700kg per arm only.
Always ensure that the mechanical safeties are engaged before any attempt is
made to work on or near the vehicle.
8.2.1 LIFTING
• Check and keep the rail channel clean of debris and any object that may hinder the movement
of the jacking beam.
• Lower the jack fully by depressing the lowering side of the pedal.
• Adjust the width of the jack lifting arms so that the rubber pads can contact the lifting points of
the vehicle recommended by the vehicle manufacturer.
• Raise the jack by depressing the lifting side of the pedal. Keep an eye on the jack when the
rubber pads contact the vehicle to ensure the proper contact. Adjust the width of the jack lifting
arms if necessary.
8.2.2 STANDING
• Stop raising the jack just as vehicle is raised off the lift runways. Confirm the vehicle is stable
and seated properly before lifting the vehicle to the desired height.
• After the vehicle is raised to the desired height, lower the jack to the nearest safeties.
8.2.3 LOWERING
• Be sure the safety area is free of people and objects.
• Raise the jack high enough to clear off the mechanical safeties and then flip the safety release
handle up off the safety.
• Lower the jack fully by keeping pressing the lowering side of the pedal.
