RP-R-4042B2, 4064B2
CHAPTER 5 – TECHNICAL SPECIFICATION
5.1A SIZE AND MAIN FEATURES OF RP-4042B2 (Ref. Figure 3A)
LIFT CAPACITY
Max. raised height: standard type
Max. raised height: alignment type
Min. lowered height: standard type
Min. lowered height: alignment type
Runway length
Runway width
Free width between runways
Width between two columns
Overall length
Overall height
Overall width
Raised time
Noise level
Rated pneumatic pressure
Working temperature
Average weight of package
5.2A ELECTRIC MOTOR OF RP-4042B2
Type
Voltage
Power
N° Poles
Speed
Motor enclosure type
Insulation class
Motor connection must be carried out referring to the attached wiring diagrams (fig.
The motor direction of rotation is shown in the label placed on the motor.
Before use of the lift, make sure to check if the motor specification shown in the nameplate of the
motor conforms to the local electric supply.
If there is over 10% fluctuation on the electrical power supply, it is suggested to use the voltage
stabilizer to protect the electrical components and system from overloading.
5.3A PUMP OF RP-4042B2
Type
Flow rate
Continuous working pressure
Peak pressure
REV. 01
RP-TOOLS Werkstatt-Technik
230V/220V-1Ph
21 / 94
4200kg
1800mm
1850mm
130mm
180mm
4808mm
512mm
912mm
2850mm
5038mm
2263mm
3154mm
60s
80 dB(A)/1m
6bar – 8bar
-10 °C - 40 °C
Standard type: 1250kg
Alignment type: 1870kg
ML90L2
2.2 KW
2
2800 rpm
B14
IP 54
Gear
3
2.1 cm
/g
180 bar
200 bar
G90N4
400V/380V-3Ph
2.6 KW
4
1375 rpm
5).
3
4.8 cm
/g
