With the FPC cable released, lift the back casing and put it on the table.
Now the main board is exposed, see Figure 12.
Figure 12 Overview of the main board. Part names:
3 Fan,
k) Disconnect the battery cable
CAUTION
Before starting the replacement of any spare part, make sure that the battery is disconnected.
Release the battery cable (see location on Figure 12) by pulling the grey part carefully away from the black part in the
direction shown on Figure 13.
14
1
2
4
5
4 Battery connector, 5 Battery,
7 Visualization device Interface (VDI) Board 2.
Figure 13 Disconnect the battery cable
6
3
7
1 2
Fan connector, FPC connector to main board,
6 Visualization device Interface (VDI) Board 1,
