ACKERMANN SMC99plus Anleitung Seite 79

Mounting
Weight
Front panel material
Front panel colour
Circuit board dimensions (W x H x D)
Front panel dimensions (W x H x D)
corridor databus length
Zone databus length
Corridor databus repeaters
Quantity of corridor databus devices
Number of zone databus devices
Max. quantity of corridor databus
devices, incl. bed data bus devices
FB 89470B1 / 10.13
Ward Management Controller Clino System 99plus (SMC99plus)
Field Bus Card
(Part No. 72700C1)
:
: max. approx. 150 g (incl. accessories set)
:
:
:
:
: 500 m (data/audio),
max. 2500 m (with repeaters)
:
:
:
:
:
255 devices
Plug-in card for SMC
PC + ABS – FR / PC
grey, similar to RAL 7035
106 x 57 x 12 mm
59 x 25 x 2 mm
---
max. 4
127 devices (repeaters required as of 64)
---
Field Bus Card
(Part No. 72700E1)
---
50 m (POF fibre),
150 m (HCS fibre)
1 km (FO fibre 50/125 µ)
75 devices
---
79
