Detailed information on the display and operating units

Cover flap
1
To seal the housing and protect against dust and mechanical damage, the SMC (Part No. 72700A1) is
equipped with a cover flap.
For more information, see section 3.2.
/ Service LEDs
2 K
The red, yellow and green service LEDs serve to display the SMC operating status and assist orientation in
the service menu. If multiple status messages are pending at the same time, the one with the highest priority
is always displayed.
Priority Status
1 Bootloader active
2 Application booting process
3 SMC in service mode
6 SMC in emergency mode
5 Fatal error
Relay for signalling faults
7
active
Power supplies (local and station)
9 connected and within
tolerance
Power supply (local or station)
8
is within tolerance
Power supply (local or station)
4
is not in tolerance
FB 89470B1 / 10.13
Ward Management Controller Clino System 99plus (SMC99plus)
LED
red
yellow
green
red
yellow
green
red
yellow
green
red
yellow
green
red
yellow
green
red
yellow
green
red
yellow
green
red
yellow
green
red
yellow
green
Flashing frequency: 1 Unit = 100 ms
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
