Ward Management Controller Clino System 99plus (SMC99plus)
1

General / Application

The Ward Management Controller 99plus - hereafter called SMC - is used in the Clino System 99plus and is
the central control unit of the system. It handles the monitoring and synchronisation of all bus devices while
also ensuring the overarching connection to other SMCs or the server.
The SMC has a modular design and can be expanded with 2 Field Bus Cards (FBC). These provide the
interfaces for the zone databus (SBUS) and the corridor databus (ZBUS) and also offer the option of
connecting a redundant power supply. Up to 64 SMCs can be networked via Ethernet or the SBUS. Up to
127 active corridor databus devices, such as room terminals and electronics modules, can be managed over
the ZBUS.
The displays, interconnections, label texts, system language etc. are configured on the operating computer
(PC). Compatibility mode support for existing system installations with the zone controllers (Part No. 72660x)
is integrated and may require updating the firmware on the installed equipment. In addition to preparation for
future firmware updates (licenses required), the SMC is equipped with an SD card slot to enable the use of
additional features.
Thanks to the various designs of the SMC, it may be installed onto a wall or in a cabinet (rack mounting).
Project-specific planning of the central equipment is only required as of 500 rooms.
Device and system design training
We constantly offer project design, planning and commissioning training courses for Ackermann
call systems . Please visit www.ackermann-clino.de or contact us at 0049 (0) 2137 / 17-600 for
more information on our training courses.
1.1

List of abbreviations

Abbreviation
SBUS
ZBUS
ABUS
BBUS
SMC / SMC99plus
FBC
ZC
1.2

Safety information

• Data retention upon power failure for at least 15 seconds acc. to DIN VDE 0834
• Option of redundant power supply via secondary power supply unit.
• Local emergency operation upon failure of the Ward Management Controller
• Sequential monitoring of the connected active devices, other controllers in the system network and the
PC communication according to DIN VDE 0834
• 2 fault signalling relays for signalling faults
Electrical isolation from other SMCs
•
• Status display via LEDs
• Flash memory for saving system data
44
Description
Zone databus
Corridor databus
Audio databus
Bed databus
Ward Management Controller Clino System 99plus
Field Bus Card
Zone Controller
FB 89470B1 / 10.13
