Ward Management Controller Clino System 99plus (SMC99plus)
7

Technical specifications

Power supply
Quiescent current
Power consumption
Current consumption
Switch-on peak
Relay max. contact load
Relay line length
Ethernet interface
Ambient temperature
Storage temperature
Humidity
Air pressure
Protection class
Field of application
Fire class
Contamination level
Environmental class
Mounting
Material
Colour
Weight
Dimensions (W x H x D)
Max. quantity of SMCs
Max. quantity of (logical)
groups
78
SMC99plus
(Part No. 72700A1)
:
:
:
:
:
:
:
:
:
:
: +20 ... + 85 % rel. hum. (non-condensing)
:
:
: B acc. to DIN VDE 0834-1 : 2000-04
:
:
:
: Surface-mounting
:
:
max. approx. 1.1 kg
:
(incl. Field Bus Cards)
: 278 x 192 x 60 mm
:
:
24 V DC ± 10%
180 mA @ 24V DC
4,4 W
max. 270 mA
2 A for 40 ms
1 A / 30 V DC
max. 30 m
10 / 100 Mbit/s
+ 5 ... + 55 °C
0 ... + 60 °C
86 ... 106 hPa
3 acc. to DIN EN 60950 : 2006
V1
2
I
PC + ABS - FR/PC
grey, similar to RAL 7035
(incl. Field Bus Cards)
64
250 (per system)
SMC99plus
(Part No. 72700B1)
In system rack
max. approx. 0.9 kg
262 x 154 x 61 mm
FB 89470B1 / 10.13
