Ward Management Controller Clino System 99plus (SMC99plus)
2

Device description

2.1

Display and operating unit (Part No. 72700B1)

The SMC is intended for installation in an equipment cabinet and is delivered with suitable fastening
materials. It may be installed in a vertical or horizontal orientation.
SMC for installation in equipment cabinet
A
B
C
D
E
F
G
H
A
Fig. 4: Display and operating element (front view)
• Always use the covers for installation slots 1 and 2 to ensure that the devices operate correctly.
• For more information about the display and operating units, see section 2.4.
50
A
I
Fastening holes
A
24 V power supply via mains adapter
B
24 V local power supply
C
2 fault signalling relays
D
J
ETH connection port (RJ45)
E
K
I
Rotary switch for addressing
F
L
MINI-USB interface
M
G
only for service functions
Field Bus Cards LEDs
H
N
Cable management
I
Service menu button
J
I
Service LEDs
K
SD card slot
L
O
Reset button
M
P
1. Installation slot for Field Bus Cards
N
2. Installation slot for Field Bus Cards
O
I
Removal hook for Field Bus Cards
P
A
FB 89470B1 / 10.13
