SMC as main panel
10.1.19.1
Z A
Patient handset
B
Room terminal
S Ward databus
Z Zone databus
B Bed databus
D Direct connection
A Audio databus
Fig. 2: SBUS networking incl. IP addresses (example 2)
LAN
SMC (IP) as main panel
10.1.19.51
Connection to
Server-PC
Bed module
L LAN
S Ward databus
Z Zone databus
B Bed databus
D Direct connection
A Audio databus
* Secoundary panel Ward data bus segment
Fig. 3: LAN / IP-networking with SBUS incl. IP addresses (example 1)
The type of SMC networking is defined by the rotary switch setting.
For more information, see section 2.1.
FB 89470B1 / 10.13
Ward Management Controller Clino System 99plus (SMC99plus)
SMC as secondary panel
10.1.10.2
Z A
Room
terminal
Bed module
Room
elektronic
Bed module
module
Pear or Multiple push-button
L
SMC (IP) as secondary panel *
10.1.19.52
S
A
B
Call push-button
RFID
module
Room terminal
S
Audio-ISDN-Interface
Display module
B
Call module
SMC as secondary panel
SMC as secondary panel
10.1.52.2
10.1.52.1
Z Z A
Room
terminal
Room
electronic
module
B
Display module
Room
electronic
module
SMC as secondary panel
10.1.10.3
Z A
ISDN
Z
A
Duty room interface
D
Databus
connection unit
Master station
Audio-ISDN-Interface
Call push-button
D
Call
push-button
B
Display module
ISDN
Multiple
push-button
