APPENDIX

Profi TX trims and telemetry for WINGSTABI

With the Profi TX software from V2.42, it is possible to operate the WINGSTABI so that
the channels for ailerons, elevator and rudder can be transferred without the trim and
the trims transferred to separate channels instead.
In the transmitter, create a new model without mixer. Use the BASIC template to do this.
Next, change the servo assignment of the transmitter as follows:
Channel assignment PROFI TX
Servo 1 Ailerons
Servo 2 Elevator
Servo 3 Rudder
Servo 4 THROTTLE
Servo 5 Spoilers
Servo 6 Flaps
Servo 7 Assign Frei 1 => here under Setup => Assign controller => enter a
switch for gyro phases 1 to 3 for Free 1
Servo 8 Assign Frei 2 => here under Setup => Assign controller => enter a
switch for gyro phase 4 for Free 2
Servo 9 Assign to QuerruderTr (purely aileron trim)
Servo 10 Assign to HöhenruderTr (purely elevator trim)
Servo 11 Assign to SeitenruderTr (purely rudder trim)
Servo 12 If desired, use this channel for controlling the sensitivity (e.g. sliders E,
F, G or H)
