Trimming using special trimming channels

If it is possible to use the trim controllers of your transmitter for special servo channels,
for instance with the Profi TX and the Royal SX (from software 3.52) as well as several
transmitters from other manufacturers, you can set up a special trim channel for each
axis and trim your model as normal this way. This trimming then effectively passes by
the gyro. The correct Profi TX programming for this purpose is described in the
appendix.
For special trim channels, trimming using fast switching can only take place after
specially activating this option. After the settings have been taken on, trimming on the
transmitter is to be set to neutral when the WINGSTABI is switched off.

Trim flight mode

For this option, a servo channel is required on the transmitter, which is on a button (if
need be it can also be a switch). It is imperative that this channel is also assigned in the
WINGSTABI model memory. The trim flight mode must also be activated when starting
the WINGSTABI: Press and hold the trim flight button and switch on WINGSTABI. The
trim flight mode is confirmed by jerking the servo five times (normally only three times).
The WINGSTABI now also no longer allows the gyro phases to be switched. Execute
the flight and use the trim(s). After landing, the trim flight button must be held down for
three seconds (this should be quite accurate). The current trims are now assumed and
the values saved. This is shown by the jerking of the servo. Now switch off the
WINGSTABI, neutralize the transmitter trims and switch the WINGSTABI back on. You
can now fly normally, in all modes.
IMPORTANT NOTE: All default settings of the WINGSTABI can be modified
!
either using the slider, the arrow keys, or by entering the exact numbers using
the keyboard. After modifications have been made, these must always be
transferred into the WINGSTABI and it is recommended that they are also
backed up in a file. For documentation purposes, backing them up again in a
PDF file is suitable.
Figure 12:Switching trim activator
Seite 21/39
