Regulation (basic)

Figure 9: Basic regulations
Sensitivity via transmitter
With the aid of a special sensitivity channel, the global sensitivity (gain) of the axis can
be influenced from the transmitter. Various areas can be adjusted – for example +/-10.
If, for example, you have set the global sensitivity to 40, and the area to +/-10, you can
vary the sensitivity via the transmitter from 30 to 50.
Sensitivity (global)
The global sensitivity affects all components of the regulator, i.e. P, I and D (explanation
on the following page). If the ideal ratio between P, I and D have been acquired through
flight, the total adjustment of the system can be carried out using global gain.
Depending on the weather conditions, it might make sense to slightly increase or
decrease the global sensitivity.
