A red flashing arrow at the top right, as in all menus which enable changes, indicates in
certain situations that the changes you made should be transferred to the gyro, simply
by clicking on the field with the arrow.
If you now switch to the advanced window, you will find the default settings which
shouldn't be modified unless absolutely necessary. The input fields also provide short
explanations for this when you move the cursor over them.
IMPORTANT NOTE: After each configuration change, the data you have for
the WINGSTABI should be backed up in a file on your computer. To do this,
!
use the "Export WINGSTABI settings" menu item in the drop-down menu right
at the top on the left. For this, name the files as clearly as possible, for instance
corresponding with the name of the model or the name of the transmitter
memory. If you want to retrieve the data again, select "Import WINGSTABI
settings" and then the file name.

Three available basic models

By clicking the airplane symbol in the menu bar, the selection window for the basic
model characteristics opens: Delta wing, classic fixed-wing aircraft and V-tail models
are available. On the same side in the basic window, the mixing of spoilers into the
ailerons and flaps activation are also available. Under "Advanced", you can even
activate a SnapFlap function for classic fixed-wing models, using which you can mix
your elevator deflections to the ailerons with a mixing ratio which can be adjusted by
percentage.
On the same page, an elevator-throttle-compensation is available. This is only required
if a model unintentionally swerves up or, more rarely, down when the motor is activated.
This is a clear sign of an incorrect downthrust, which can be easily corrected here using
an automatic elevator or hydroplane mixing. The point at which the mixing should be
applied can be precisely determined by the minimum throttle value.
