The first step is to program a switch channel with three stages in the transmitter and
then enter this in the receiver menu of the WINGSTABI under "Flap control => flap
phases". We will do without the fourth flap phase here for the time being. Now, in the
model menu, as explained previously, activate the flap control under "Flap settings =>
Control" with the option "Using switch channel".
In the "Servo settings menu", we assign one servo for the "Inner flap 1" and one servo
for the "Inner flap 2".
Now open the new "Flap control" menu item in the symbol bar to reach the "Basic
settings". We define the flaps in this case as "Spoilers", and set their movement speed
to around 30, so that the flaps do not extend and retract abruptly, but rather move
slowly and prototypically. The higher the value in this field, the slower the flap servos
run.
Figure 15: Basic flapsettings
