Installation position

Figure 1: Installation position side view
Figure 2: Installation position view from above
IMPORTANT NOTE: The gyro must be installed completely in parallel to the
!
flight axis securely in the model. It is imperative that this is observed for all
three axes of the model or the WINGSTABI! Tilted positions lead to corrections
with the wrong control surface, vibrations can unsettle the system (velcro
fastening is therefore NOT recommended).
