The alternative method
Another possible way of achieving the same thing is to assign a spoiler channel instead
of the flap phases in the receiver menu. This is then controlled at the transmitter end by
a slider or alternatively a three-stage switch (defined as a controller).
The servo assignment is the same as above, as are the basic settings in the flap
control. Only in flap phase 1 do we leave the fixed value for spoilers on "0", and instead
tick the "Proportional spoiler input" field.
Figure 17: Alternative phase settings
It is now possible to move the flaps proportionately using the slider on the transmitter, or
to switch using a three-stage controller. The advantage of this solution with the three-
stage controller is that it is possible to quickly change the flap settings "half" and "full" on
the airfield by changing the servo travel from the transmitter, whereas you would have
to connect to a PC or Android to perform the same task with the fixed values of the first
solution.
