Differential (D input)
The D input reacts to how strongly the last correction was regulated against. The D
factor therefore serves to accelerate the regulation. Please use the D input very
carefully. Increase the D sensitivity in small increments starting at 0. If the D input is set
too high, this quickly causes the model to oscillate.
Sensitivity
If the D input is set too high, the corresponding axis can oscillate quickly. It oscillates
when the stick returns to the center.

Tool menu

Here, you can adjust the servo travels (min–neutral/medium–max) of your transmitter to
the servo travels selected in the WINGSTABI. The adjustment should always be in the
green area. Readjust the travels in the transmitter if they stray into the orange areas.
There is also a menu item for controlling the effective direction of the sensors here. In
addition, the instructions for the WINGSTABI are effectively "online".
Figure 11: WINGSTABI tool menu
Seite 19/39
