IMPORTANT NOTE: Batteries connected to the WINGSTABI pro are to be
removed at the end of the flight, even if a switch is used for the integrated
battery switch, as the batteries would otherwise slowly but surely discharge due
to the residual current.
For the WINGSTABI with the integrated receiver, the signal transmission between the
receiver and the gyro works automatically. For external receivers, the correct signal
setting must be observed. External MPX receivers must be set via launcher to
MULTIPLEX SRXL; other systems require other settings for the serial data connection.
Observe the instructions of your receiver for this.
If you are a beginner when it comes to controlling the gyro, the "Assistant" is the right
choice, unless you are equipping one of the models listed in the "Model template" box.
The "Assistant" takes you step by step through the basic configuration with lots of
explanations including the correct receiver selection in terms of serial signal format for
external receivers. The correct channel assignment, model type and servo type can be
determined by moving the respective transmitter stick. The servos are connected to the
WINGSTABI as shown in the diagram and its movement direction is verified. The
positioning of the gyro in the model is requested in order to be able to subsequently
check the effective direction of the correction deflections. After this, configuration has
been successfully completed and fine adjustments can be made.
If you retrieve one of the integrated model templates, you are taken through the same
steps, but the optimal gyro settings for the selected model are pre-selected. If you
purchased the model as "RR version" from MPX, the positioning of the gyro and the
movement and effective directions as well as the deflections of all servos have of
course already been programmed in, and must only be verified.
The "Import" option allows you to retrieve gyro configurations which you already have
stored on your PC. These can either be your own files or those from other WINGSTABI
users. The files must be stored in the correct folder. The configuration file names end in
".wcf" (wingstabi configuration file).
If you select the "Manual" option right at the start, you are taken directly to the start
screen, which is based on one of the basic configurations stored in the WINGSTABI.
Now you must work your way manually through the menu pages relating to servo
assignment, servo types, servo movement directions, channel assignments and so on,
in order to adjust the WINGSTABI to the actual configuration of your model.
