Trimming the model

It is generally not allowed to trim on the transmitter when using the WINGSTABI, as in
heading mode every trim would be received as a desired control surface position
change. If necessary, as long as you only use the damping (phase 2) of the
WINGSTABI or have switched off the WINGSTABI via phase 1, you can trim. Trimming
can be used to properly fly in the model for the first time. Any trimming carried out after
that is assumed mechanically, in order to then neutralize the trim on the transmitter
again. The trim flight mode is available as an alternative.

Trim settings by quick switch

There is another trim travel: Select gyro phase 1 at the start and do not switch to other
gyro phases during flight. Use the trim on the transmitter, until the model is in neutral
flight. Now land the model. By quickly toggling the gyro phase switch, the affected trim
settings must now be transferred to the WINGSTABI and taught in.
Procedure: Quickly move the gyro phase switch to and fro 4 to 5 times. This will enable
the trim settings gained through flight to be taught into the WINGSTABI as the neutral
position. You can monitor the programing of the trim settings by switching to gyro
phases 3 or 4. It must now be ensured that the trimmed control surfaces do not "stray"
out of the neutral position.
Now you can theoretically take off again immediately, whereas of course all phases may
be used. It makes more sense to switch off the WINGSTABI after successfully setting
the trim, setting the trim on the transmitter back to neutral and then switching the
WINGSTABI back on again. Now it takes the center positions, which were taught in
previously using the trim settings, as standard and you have the entire trim travels at
your disposal on the transmitter again should you need them.
!
IMPORTANT NOTE: During initial flight of the model, you should only fly in
phase 1 using one of the above mentioned trim methods. You may only fly in
"supported" phases once the model has been trimmed correctly and the trim
values have been saved in the WINGSTABI.
