Now you can define the function and type of the servo on the right hand side.
Depending on the gyro version, varying numbers of outputs are available. In the middle
next to the conventional HiTEC servo, adjust the servo center and the two end positions
as required in the model for the designated rudder deflections. The values 1100, 1500
and 1900 are set as default. With MPX systems, values up to 1000, 1500 and 2000 are
recommended. If necessary, the direction of rotation of each servo can also be changed
here.
At the end of the servo settings, you can determine for each servo individually what it
should do in case of a loss of reception. With modern brushless regulators for throttle,
"Deactivate servo" is the optimal selection. Otherwise, you can choose between "Hold
position" (standard) or "Set position". For the latter, it is possible to assume the current
servo position or any position by keyboard entry or with the arrow keys.
Hint: For motor regulators which are operated via the WINGSTABI and which provide
adjustable idle and full throttle positions, you must teach in these positions again!

Setting up the gyro sensor

In the sensor menu item, on the right next to the servo symbol, the installation position
and effective direction of the WINGSTABI can be adjusted in the basic window.
Normally, you will have already done this at the beginning in the assistant mode. In the
advanced window, you can also adjust settings for low-pass filter and deadband.
However, you should not change the default settings for these unless absolutely
necessary. For a model with a combustion engine and strong vibrations, the regulation
can for instance be improved by a smaller cutoff frequency for the low-pass filter.
