15
Kabel
15.1
Überblick zu Kabeln
Nr.
Teilenummer
C1
T26139-Y4015-V301
C2
T26139-Y3959-V301
C3
T26139-Y3990-V301
C4
T26139-Y4028-V103
C5
T26139-Y3994-V301
C6
T26139-Y4015-V601
C7
T26139-Y3999-V501
C8
T26139-Y3964-V301
C9
T26139-Y4041-V1
C10 T26139-Y3956-V3
C11
T26139-Y4040-V2
C12 T26139-Y4040-V3
C13 T26139-Y3959-V351
C14 T26139-Y3959-V302
C15 T26139-Y4042-V2
C16 T26139-Y3987-V1
C17 T26139-Y4032-V1
RX1330 M1
Beschreibung
CBL FRONT_PANEL
CBL_HDD_2.5_POWER
CBL_ODD_Power
CBL SATA 530
CBL_Front_VGA
CBL_OOB_HDD_2BP
CBL_FRONT_USB
CBL_4HDD_DATA3.5
CBL_PDB_POWER
CBL_PDB_SIDEBAND
CBL 4HDD SAS 2.5
CBL 4HDD SAS 2.5
CBL_HDD_3.5_POWER
CBL PWR HDD 10X2.5
CBL FLEXP 22PL 600
LTG IBBU 700
CBL FBU02 620
Upgrade und Maintenance Manual
Von - an
System Board an Frontblende
System Board an HDD-
Backplane 1
System Board an ODD-
Stromversorgung
System Board an ODD-Daten
System Board an Front-VGA
System Board an HDD-
Backplane 1 und 2
System Board an Front-USB
System Board oder RAID-Karte
an 3,5-Zoll-HDD-Backplane
System Board an Power-
Distribution-Board
System Board an Power-
Distribution-Board
RAID-Karte an 4 x 2,5-Zoll-HDD-
Backplane
RAID-Karte an 4 x 2,5-Zoll-HDD-
Backplane, L-Form
Von System Board an 3,5-Zoll-
HDD-Backplane
Von System Board an 10x 2,5-
Zoll-HDD-Backplane
System Board an Frontpanel am
Montagewinkel
(Das Frontpanel am
Montagewinkel und das
Frontpanel-Kabel sind zusammen
ein Ersatzteil.)
BBU an RAID-Karte
FBU an RAID-Karte
293
