2. Unscrew the oil dipstick (12).
3. Fill the tank with engine oil using a funnel (not in-
cluded in scope of delivery). Note the max. filling
capacity of 600 ml. Carefully fill the oil up to the
lower edge of the filling port.
4. Wipe the oil dipstick (12) with a clean, lint-free cloth.
5. Reinsert the oil dipstick (12) and check the oil lev-
el without screwing the dipstick tight again.
6. The oil level must be within the middle mark on
the oil dipstick.
7. If the oil level is too low, add the recommended
amount of oil (max. 600 ml).
8. Then screw the oil dipstick (12) in again.
9.2 ) L OOLQ J X S ZLWKSHWURO) L J
m ' $ 1 *(5
5LVNR I ¿ U H DQGH [ S OR V LR Q
When filling, fuel may ignite and even explode. This
can lead to severe burns or death.
- Switch off the engine and let it cool down.
- Keep heat, flames and sparks away.
- Only fill up with fuel outdoors.
- Wear protective gloves.
- Avoid contact with skin and eyes.
- Start the product at a distance of at least 3 m from
the fuel filling point.
- Watch out for leaks. If petrol is leaking, do not start
the engine.
m � $ W W H Q W L R Q �
7 K H � G X P S H U � L V � G H O L Y H U H G � Z L W K R X W � S H W U R O � � , W � L V �
W K H U H I R U H � H V V H Q W L D O � W R � � O O � Z L W K � S H W U R O � E H I R U H � F R P
PLVVLRQ L Q J 8VHRQ O \ 521X Q O HDGHGSHWURO
1. Clean the area surrounding the filling area. Impu-
rities in the tank lead to operational faults.
2. Carefully open the tank cover (16) so that any
possible overpressure can be relieved.
3. Fill the fuel tank (15) with petrol using a funnel
(not included in scope of delivery). Note the max.
filling capacity of 4.2 litres. Carefully fill the petrol
up to the lower edge of the filling nozzle.
4. Close the tank cover (16) again. Ensure that the
fuel cap is tightly sealed.
5. Clean the fuel cap and the surroundings.
6. Check the tank and fuel lines for leaks.
7. Move at least three meters away from the refuel-
ling area before starting the engine.
10. Start-up
m � $ 7 7 ( 1 7 , 2 1 �
Before starting work, always check that the transport
tray (6) is securely locked!
10.1 2Q 2‡ VZLWFK) L J
The ON/OFF switch (2) activates or deactivates the
ignition system. The ON/OFF switch (2) must be in
the ON position for the engine to run.
36 | GB
The engine stops when the ON/OFF switch (2) is
moved to the OFF position.
10.2 & O X W FKOHYHU) L J
• Operating the clutch lever (19)
- Clutch engaged:
First press the unlocking lever (20) (Fig. 11).
Then, the clutch lever (19) can be pushed down.
• Disengaging the clutch lever (19)
- Clutch disengaged.
10.3 7KURWWOH) L J
The throttle (1) controls the speed of the engine. If
the lever is moved in the directions shown, the engine
runs faster (H) or slower (L).
Fast =
Slow =
10.4 & K RNHOHYHU) L J
• Warm engine / choke open:
• Cold engine / choke closed:
Note: The closed position of the choke lever enriches
the fuel mixture for starting a cold engine.
The open position provides the correct fuel mixture
for normal operation after starting and for restarting
a warm engine.
-
10.5 ) X H OYDOYH) L J
• Open fuel valve:
• Fuel valve closed:
10.6 /HIWVWHHULQ J OHYHUDQ G ULJKWVWHHULQ J OH
YHU) L J
• Operate the left steering lever (18) to steer to the left.
• Operate the right steering lever (3) to steer to the
right.
10.7 *HDUVHOHFWRUOHYHU) L J
• The gear selector lever (14) controls the forward or
reverse movement of the machine.
• It is possible to choose between 3 forward gears and
one reverse gear using the gear selector lever (14).
10.8 7UDQ V SRUWWUD\ WLOWOHYHU) L J
: D WFK RX W IRU VX G GHQ FKDQ J HV LQ WKH FHQ W UH RI
JUDYLW\ ZKHQ WLSSLQ J RX W
% H IRUH VWDUWLQ J ZRUN DOZD\ V FKHFN WKDW WKH
WUDQ V SRUWWUD\ LVVHFX U HO\ ORFNHG
1. Pull the transport tray tilt lever (6) towards you
with your right hand. This will unlock the tray fix-
ing (7). (Fig. 13)
