Latchsteuerwort und Latchstatuswort

Latch-Steuerwort (2 Byte)
Bit
5-7
8-12
13-15
Latch-Statuswort (2 Byte)
Bit
5-7
8-11
12-15
32
Wert (bin)
0 00000000 00000001
1 00000000 00000010
2 00000000 00000100
3 00000000 00001000
4 00000000 00010000
00000001 00000000
00000010 00000000
00000011 00000000
00000100 00000000
00000101 00000000
Wert (bin)
0 00000000 00000001
1 00000000 00000010
2 00000000 00000100
3 00000000 00001000
4 00000000 00010000
00000001 00000000
00000010 00000000
00000011 00000000
00000100 00000000
00000101 00000000
00010000 00000000
00100000 00000000
01000000 00000000
10000000 00000000
04/2016
Beschreibung
Wert (hex)
xx01 Enable extern latch 1 (positive rise)
xx02 Enable extern latch 1 (negative rise)
xx04 Enable extern latch 2 (positive rise)
xx08 Enable extern latch 2 (negative rise)
xx10 Enable intern latch C (positive rise)
Reserve
01xx Read external latch 1 (positive rise)
02xx Read external latch 1 (negative rise)
03xx Read external latch 2 (positive rise)
04xx Read external latch 2 (negative rise)
05xx Read external latch C (positive rise)
Reserve
Wert (hex) Beschreibung
xx01 External latch 1 valid (positive rise)
xx02 External latch 1 valid (negative rise)
xx04 External latch 2 valid (positive rise)
xx08 External latch 2 valid (negative rise)
xx10 Internal latch C valid (positive rise)
Reserve
X1xx Acknowledge value external latch 1 (positive rise)
X2xx Acknowledge value external latch 1 (negative rise)
X3xx Acknowledge value external latch 2 (positive rise)
X4xx Acknowledge value external latch 2 (negative rise)
x5xx Acknowledge value internal latch C (positive rise)
1xxx Zustand Digital Input 4
2xxx Zustand Digital Input 3
4xxx Zustand Digital Input 2
8xxx Zustand Digital Input 1
