• Do not begin cleaning the blade until it has come to
a complete standstill.
• For straight cuts of small work pieces against the
longitudinal limit stop the push stick has to be used.
• Wear gloves when handling the saw blade and
rough materials
• The band saw blade guard should be in its lowest
position close to the bench during transport.
• For miter cuts when the table is tilted, the parallel stop
must be positioned on the lower part of the table.
• Never use guards to lift or transport items.
• Ensure that the band saw blade guards are used and
correctly adjusted.
• Keep your hands a safety distance away from the
band saw blade. Use a push stick for narrow cuts.
• The push stick has to be stored on the intended de-
vice, so that it can be reached from normal working
position and is always ready to be used.
• In the normal operating position the operator is in
front of the machine.
m WARNING! This electric tool generates an electro-
magnetic field during operation. This field can impair
active or passive medical implants under certain con-
ditions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical im-
plants consult with their physician and the manufacturer
of the medical implant prior to operating the electric tool.
Remaining hazards
The machine has been built using modern technology
in accordance with recognized safety rules. Some re-
maining hazards, however, may still exist.
• Risk of injury for fingers and hands by the rotating saw
band due to improper handling of the work piece. Risk
of injury through the hurling work piece due to improp-
er handling, such as working without the push stick.
• Risk of damaging your health due to wood dust and
wood chips. Wear personal protective cloth such as
goggles. Use a fitting dust extractor.
• Risk of injury due to defective saw band. Regularly
check saw band for such defects.
• Risk of injury for fingers and hands while changing
saw band. Wear proper gloves.
• Risk of injury due to starting saw band while switch-
ing on the machine.
• The use of incorrect or damaged mains cables can
lead to injuries caused by electricity.
• Wear only close fitting clothes. Remove rings,
bracelets and other jewelry.
• For the safety of long hair, wear a cap or hair net. Even
when all safety measures are taken, some remaining
hazards which are not yet evident may still be present.
• Remaining hazards can be minimized by follow-
ing the instructions in „General safety instructions"
„Proper Use" and in the entire operating manual.
6. Technical Data
Electro motor
Power
Revolutions n0
Saw band length
Saw band width
Saw band width max.
Cutting speed
Passage height
Passage width
Table size
Table size with min.
extension
Table size with max.
extension
Slewing range of the table
Max. size of the workpiece
Overall weight
Subject to technical modifications!
* Operating mode S1, continous operation.
The work piece must have a minimum height of 3 mm
and a minimum width of 10 mm.
The total noise values determined in accordance with
EN 62841.
Sound pressure level L
Uncertainty K
Sound power level L
Uncertainty K
Wear hearing protection!
The effects of noise can cause a loss of hearing. Keep
the noise level and vibration to a minimum!
www.scheppach.com
230 - 240 V ~ 50 Hz
S1 250 W, S2 30
400 x 400 x 80 mm
pA
pA
WA
WA
min 350 W
1400 rpm
1400 mm
6 - 12 mm
12 mm
900 m/min
0 - 80 mm
200 mm
300 x 300 mm
380 x 300mm
535 x 300mm
0° bis 45°
19 kg
77.4 dB
3 dB
90.4 dB
3 dB
