EN
Using the MSA PRD
Fitting and adjusting the harness (continued)
Note: If adjustment of the shoulder straps is required, remove the
harness and undo the zips on either side of the backpack(Figure
13). Adjust the shoulder straps by sliding the shoulder strap
adjustment buckles and cross strap buckle (where the shoulder
straps cross). Check adjustment by continuing to try on the harness
until the chest strap and connection point are correctly positioned.
Figure 13
• Connect the leg buckles
pulling the straps through the buckles to achieve a snug fit (Figure
14).
Figure 14
• Where included (RH3 harness only), connect the waist belt buckle at
the front, and adjust the strap by pulling the strap through the buckle
to achieve a snug fit (Figure 15). It is essential to regularly check
the fastening and adjustment elements during use. The waist belt is
approved for a user, including tools and equipment, with a weight of
up to 150kg.
Figure 15
• Use the plastic sliders to secure any free strap. (Figure 16).
Figure 16
12
(B)
(Figure 11). Adjust the leg strap by
• Connect the karabiner of the energy absorbing lanyard to the fall
arrest attachment point marked
attachment point that will operate the MSA PRD rescue function.
A
1
Figure 17
• C: Plastic breakaway lanyard stowage points. Not a fall arrest
attachment point.
A
2
D: Stainless steel toolbag attachment point. Not a fall arrest
C
C
attachment point.
E
E
A
2
: Front (chest) attachment. For climbing/fall arrest only
D
E: Side attachments (where included). For work positioning only
—not a fall arrest attachment point.
Figure 18
(Figure 18).
When the harness is worn for extended periods of time, straps and
adjustment buckles shall be regularly checked to ensure a snug fit is
maintained.
Additional fall arrest attachments
Additional fall arrest attachment points are provided on some harness variants. These may be
used as attachments for energy absorbing lanyard/ladder climbing equipment and work.
The MSA PRD rescue facility will operate on the rear attachment point
Work positioning attachments
Some harness variant include side attachment points. These attachments shall only be used with a
suitable work positioning lanyard, adjusted to restrict the wearer's movement to a maximum of 0.6 m.
The intention of this is to allow the user to secure themselves in position to free up hands for work.
Where work positioning is used, this shall always be backed up with a fall arrest system (e.g. energy
absorbing lanyard) attached to the front or rear attachment. A work positioning lanyard should never
be the sole method of protecting the User.
EN
A
A
(Figure 17).
is the only
1
1
A
only.
1
13
