ENGLISH
Liquid gas
Turn off the gas supply tap.
1)
Undo the screws (B) and remove the control
2)
panel (A).
Unscrew the cap (E).
3)
Remove the adjuster screw (G), the spring (F)
4)
and replace them with the cap (H) (supplied
on request).
Screw the cap (H) fully down.
5)
Restore the initial conditions after completing
6)
the operation.
To carry out this operation, proceed as follows.
Turn off the gas supply tap
1)
Open the hatch (A).
2)
Remove the guard (B).
3)
Undo the locking screw (C).
4)
INSTRUCTIONS AND WARNING FOR REPLACING PARTS
NOTE: Read the following section of
the "user instruction manual" carefully be-
fore replacing any part:
– Hazards and safety provisions during instal-
lation and commissioning, adjustments and
part replacement.
16
ADJUSTING BURNER PRIMARY AIR
REPLACING PARTS
Set the bush (E) at the distance (D) shown in
5)
the diagram.
Tighten the screw (C).
6)
Replace the guard (B).
7)
Close the hatch (A).
8)
WARNING: Before making any type
of adjustment, activate all the safety devices
provided and decide whether staff at work
and those in the vicinity should be informed.
In particular, close the the gas and water sup-
ply taps, cut off the electricity supply using the
master switch and prevent access to all devic-
REPLACING PARTS
