Parametrierung
7.4.3.1 Attribute 1, Number of Attributes
Number
Position Sensor Object.
7.4.3.2 Attribute 2, Attribute List
Attribute List liefert die unterstützten Attribute des Position Sensor Object
als HEX-Wert zurück:
ARRAY (USINT), nur lesen
Attr.-ID
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
TR-Electronic GmbH 2013, All Rights Reserved
Page 38 of 175
of
Attributes liefert die Anzahl der unterstützten Attribute des
HEX-Wert
1
0x01
2
0x02
10
0x0A
11
0x0B
12
0x0C
15
0x0F
16
0x10
17
0x11
18
0x12
19
0x13
21
0x15
22
0x16
23
0x17
24
0x18
25
0x19
26
0x1A
27
0x1B
28
0x1C
42
0x2A
43
0x2B
44
0x2C
45
0x2D
46
0x2E
47
0x2F
48
0x30
49
0x31
50
0x32
51
0x33
0x64
0x65
0x66
0x67
0x68
0x69
0x6A
0x6B
0x6C
0x6D
0x6E
0x6F
0x70
0x71
0x72
TR-ECE-BA-DGB-0102 v10
Name
Number of Attributes
Attribute List
Position Value Signed
Position Sensor Type
Direction Counting Toggle
Position Format
Measuring Units per Span
Total Measuring Range in Measuring Units
Position Measuring Increment
Preset Value
Position State Register
Position Low Limit
Position High Limit
Velocity Value
Velocity Format
Velocity Resolution
Minimum Velocity Setpoint
Maximum Velocity Setpoint
Physical Resolution Span
Number of Spans
Alarms
Supported Alarms
Alarm Flag
Warnings
Supported Warnings
Warning Flag
Operating Time
Offset Value
Position Value Extended
Total Measuring Range
Number of Revolutions - Numerator
Number of Revolutions - Denominator
Preset Value Extended
TR-Parameter in use
Temperature Value
Temperature Value Format
Temperature Low Limit
Temperature High Limit
Additional Vendor-Parameter 1 (Reserviert)
Additional Vendor-Parameter 2 (Reserviert)
Accept Parameter
Encoder Firmware Number
Encoder Firmware Version
