Parameterization
7.4.3.33 Attribute 107, Temperature Value Format
Temperature
Temperature Value" and the input unit of "Attribute 108, Temperature Low Limit" and
"Attribute 109, Temperature High Limit".
ENGUNIT
Value
0x1F04
0x1F05
Connection path, Packed EPATH with 8 bit class
0x20
Logical Type
= Class
This attribute only takes effect after executing service code 0x16 save or attribute 112
Accept Parameter.
7.4.3.34 Attribute 108, Temperature Low Limit
Temperature Low Limit defines the minimum value of the temperature with the
unit that is defined in "Attribute 107, Temperature Value Format" it is standardly °C. If
this value falls below in "Attribute 47, Warnings" the depending warn bit (13) is set to
high.
INT, Default: - 20 °C
2
Connection path, Packed EPATH with 8 bit class
0x20
Logical Type
= Class
To save this attribute permanently the attribute 112 Accept Parameter or service
code 0x16 save must be executed.
TR-Electronic GmbH 2013, All Rights Reserved
Page 148 of 175
Value
Format
Unit
degree Celsius [°C]
degree Fahrenheit [°F]
0x23
Logical Type
Class #23
Temperature Low Limit
Byte 0
Byte 1
7
0
15
up to 2
2
0x23
Logical Type
Class #23
TR-ECE-BA-DGB-0102 v10
defines the output unit of "Attribute 106,
0x24
0x01
Instance #1
= Instance
8
up to 2
0x24
0x01
Instance #1
= Instance
Default
X
0x30
0x6B
Logical Type
Attr.-ID #107
=Attr.-ID
0x30
0x6C
Logical Type
Attr.-ID #108
=Attr.-ID
Printed in the Federal Republic of Germany
01/27/2022
