Commissioning
LED4: Net Status
LED status
OFF
ON
FLASHING
(green)
ON
FLASHING
(red)
For appropriate measures in case of error see chapter "Causes of faults and
remedies" on page 170.
5.3 MAC-Address
Already by TR-Electronic each EtherNet/IP™ device a worldwide explicit device
identification is assigned und serves for the identification of the Ethernet node. This 6
byte long device identification is the MAC-Address and is not changeable.
The MAC-Address is divided in:
●
3 Byte Manufacturer-ID and
●
3 Byte Device-ID, current number
Normally the MAC-Address is printed on the connection hood of the device.
E.g.: "00-03-12-04-00-60"
TR-Electronic GmbH 2013, All Rights Reserved
Page 108 of 175
Description
Not powered, no IP address
(green) Connection established
No connection
(red)
The device has detected that its IP address is already in use
One or more of the connections in which this device is the target
has timed out. This state is left only if all timed out connections are
re-established or if the device is reset.
TR-ECE-BA-DGB-0102 v10
Printed in the Federal Republic of Germany
01/27/2022
