Parameterization
7.4.3.7.2 Attribute 17, Total Measuring Range in Measuring Units
Total Measuring Range in Measuring Units defines the total number of
steps of the measuring system before the measuring system restarts at zero.
UDINT
2
Access
Lower limit
Upper limit
Default
At measuring ranges ≥ 32 bit, the "Attribute 101, Total Measuring Range" on page
142 must be used.
Connection path, Packed EPATH with 8 bit class
0x20
Logical Type
= Class
This attribute only takes effect after executing service code 0x16 save or attribute 112
Accept Parameter.
The actual upper limit for the measurement length to be entered in steps is dependent
on the measuring system version and can be calculated with the formula below. As
the value "0" is already counted as a step, the end value = measurement length in
steps - 1.
Formula 1: General Scaling parameter
TR-Electronic GmbH 2013, All Rights Reserved
Page 130 of 175
Byte 0
Byte 1
7
0
15
up to 2
2
Set / Get
16 steps
4 294 967 295 (32 Bit)
16777216
0x23
Logical Type
Class #23
Total measuring range = Steps per revolution * Number of revolutions
TR-ECE-BA-DGB-0102 v10
Total Measuring Range
Byte 2
8
23
up to 2
2
up to 2
0x24
0x01
Instance #1
= Instance
Byte 3
16
31
24
2
up to 2
0x30
0x11
Logical Type
Attr.-ID #17
=Attr.-ID
